500L/H automatic chemical dosing system equipment Integrated vertical PE dosing device
The dosing system is a complete set of equipment integrating dosing, mixing, liquid transportation and automatic control. It is widely used in the raw water, boiler feed water, oilfield surface gathering and transportation dehydration treatment systems of power plants, various petrochemical dosing systems and wastewater treatment systems. Such as adding coagulant, phosphate, ammonia, lime water, corrosion inhibitor, scale inhibitor, bactericidal and algal killing agent, etc.
Working principle
The dosing device is configured in the mixing box according to the required reagent concentration. After being stirred evenly by the agitator, it is put into the solution tank, and the metering pump is used to transport the prepared solution to the dosing point or the designated system.
Main features
a. Centralized design, small footprint, simple structure and stable performance;
b. Convenient measurement and adjustment, good economy, and easy installation and maintenance;
c. The pump is installed in suction type, which is not easy to block, with long trouble free operation time and low operation cost;
d. Excellent corrosion resistance and long service life.
Parameters
| Type | QJY-500 | QJY-1000 | QJY-1500 | QJY-2000 | QJY-3000 | |
| production abilityQ(L/h) | 500 | 1000 | 1500 | 2000 | 3000 | |
| Size | 900x1500x1650 | 1000 x 1625 x1750 | 1000 x 2440x1800 | 1220 x 2440 x180C | 1220x3200x2000 | |
| Powder Dosing PowerNi(KW) | 0.18 | 0.18 | 0.18 | 0.18 | 0.18 | |
| blender | Blade diameterG(mm) | 250 | 250 | 250 | 250 | 250 |
| Vertical spindle speed(i/min) | 96 | 96 | 96 | 96 | 96 | |
| PowerN2(KW) | 0.55 x 2 | 0.55x2 | 0.55 x 2 | 0.55x2 | 0.55x2 | |
| Dosing screw pump | Flow Q2(mV h) | 1 | 1 | 1.5~2.0 | 1.5-2.0 | 3.0~ 5.0 |
| Lifth(m) | 20 | 20 | 20 | 20 | 20 | |
| Power N3(KW) | 1.1 | 1.1 | 1.5 | 1.5 | 2.2 | |
| Water Inlet Dia(mm) | 20 | 20 | 25 | 25 | 32 | |
| Water outlet Dia(mm) | 20 | 20 | 25 | 25 | 32 | |
| Installation | B | 900 | 1000 | 1000 | 1220 | 1220 |
| L | 1500 | 1625 | 2440 | 2440 | 3200 | |
| H | 1650 | 1750 | 1800 | 1800 | 2000 | |
| Hi | 800 | 1050 | 1050 | 1050 | 1350 | |
