High Fiber Bundle Filter Wastewater Treatment Tank Water Reuse
Introduction
The high-efficiency fiber bundle filter is a pressure-type fiber filtration equipment with advanced structure and excellent performance. It uses a new type of bundled soft filler-fiber as the filter element. The filter material has a diameter of tens of microns or even a few microns, and has the advantages of large specific surface area and low filtration resistance, which solves the problem of filtering accuracy of granular filter media. Filter material particle size limitation and other issues. The small diameter of the filter material greatly increases the specific surface area and surface free energy of the filter material, increases the chance of contact between the impurity particles in the water and the filter material and the adsorption capacity of the filter material, thereby improving the filtration efficiency and the ability to intercept dirt.
Parameters
| specifications and models |
imports and exports DN/mm |
Backwash import and export DN/mm |
Drain outlet DN/mm |
Straight straight H/mm |
overall height H/mm |
Direct cylinder section H1/mm |
Rate of flow m3/h |
| LX-1000 | 08 | 08 | 50 | 1000 | 1790 | 009 | 30 |
| LX-1200 | 100 | 100 | 65 | 1200 | 1970 | 009 | 44 |
| LX-1400 | 125 | 125 | 65 | 1400 | 2240 | 009 | 60 |
| LX-1600 | 125 | 125 | 08 | 1600 | 2340 | 009 | 80 |
| LX-1800 | 150 | 150 | 08 | 1800 | 2500 | 600 | 100 |
| LX-2000 | 150 | 150 | 100 | 2000 | 2650 | 600 | 120 |
| LX-2200 | 150 | 150 | 100 | 2200 | 2750 | 600 | 156 |
| LX-2400 | 150 | 150 | 100 | 2400 | 2880 | 009 | 180 |
| LX-2600 | 150 | 150 | 125 | 2600 | 2950 | 600 | 220 |
Application
The fiber bundle filter can effectively remove suspended solids in water, and at the same time, it has obvious removal effect on bacteria, viruses, macromolecular organic matter, colloids, iron, manganese, etc. in the water. It has fast filtration speed, high precision, and large interception capacity. It has the advantages of convenient operation, reliable operation and no special maintenance. The equipment is widely used in electric power, petroleum, chemical industry, metallurgy, papermaking, textile, food, beverage, tap water, swimming pool and other industrial, civil water supply, process water, circulating cooling water, and wastewater filtration treatment.
Structure and Working Principle
The fiber bundle filter cancels the "capsule water filling" system, and the equipment consists of a fixed porous plate, a movable porous plate, a fiber bundle filter material, and a gas distribution device. The movable porous plate can move up and down. When filtering, under the action of hydraulic pressure, the gap of the filter material along the direction of the water flow becomes smaller and larger, and the fiber density becomes larger, forming an ideal filtration layer. The filtration process includes both vertical and horizontal filtration. Deep filtration effectively improves the filtration accuracy and filtration speed. When cleaning, the fiber bundle is loosened. At the same time, the method of air-hydration washing is adopted. During the bubble gathering and water washing process, the fiber bundle is in a constant shaking state. Under the action of water power and rising air bubbles, the filter material is backwashed to regenerate it.
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
