Industrial Wastewater Treatment Tank Absorbing Carbon Filter
Attention:
All types of equipments can be customized according your requirement. Please feel free to tell your parameters, flow charts or other demands. Quick Reply will be delivered in 12 hours by email or online chat.
Application
Activated carbon filter is a commonly used water treatment equipment. The tank is filled with activated carbon, which can be used as the pretreatment of the water treatment desalination system. Grade reverse osmosis membranes, ion exchange resins, etc. are poisoned by free residual oxygen pollution, relatively completely reduce the chroma of the water, and remove the peculiar smell in the water.
Activated carbon is a very fine carbon particle with a relatively large specific surface area. The carbon particles have finer pores-capillaries. This kind of capillary has a great adsorption capacity and can fully contact with impurities. The adsorption capacity of activated carbon is directly proportional to the contact time with water. The longer the contact time, the better the filtered water quality.
Structure and Working Principle
Activated carbon filter is a kind of more commonly used water treatment equipment. As the pretreatment of water treatment desalination system, it can absorb residual chlorine that cannot be removed in the pre-filter, which can effectively ensure the service life of the subsequent equipment, improve the quality of the effluent, and prevent pollution, especially Prevent the post-stage reverse osmosis membrane, ion exchange resin and other free residual oxygen poisoning pollution. At the same time, it also adsorbs pollutants such as small molecular organics leaked from the previous stage, and has a relatively obvious adsorption and removal effect on peculiar smell, colloids and pigments, heavy metal ions in the water, and it also has the effect of reducing COD.
parameters
| Model | External dimensions | Maximum treated water volume(t／h) | Operating weight (ton) |
| GHT-1500 | Φ 1500*3350 | 17~20 | 9.32 |
| GHT-2000 | Φ 2000*3780 | 31~37 | 15.5 |
| GHT-2400 | Φ2400*3900 | 45~54 | 21.85 |
| GHT-2600 | Φ 2600*3950 | 53~63 | 26.45 |
| GHT-2800 | φ 2800*4100 | 60~72 | 29.3 |
| GHT-3000 | Φ 3000*4200 | 70~80 | 33.55 |
| GHT-3200 | ф3200*4350 | 80~96 | 40.25 |
| GHT-3400 | ф 3400*4400 | 90~108 | 45.5 |
Main Features
1. Increase the degree of water purification and the service life of carbon.
2. Performance against peculiar smell, organic matter, colloid, iron and residual chlorine in the water body;
3. It also has a good effect on reducing the turbidity and chromaticity of the water body, purifying the water quality, and reducing the pollution of the subsequent systems (reverse osmosis, ultrafiltration, ion exchanger), etc.
4. High efficiency, low operating cost and low maintenance cost
5. Low one-time investment, small head loss, loose water quality requirements
6. The effluent quality is stable and the filtering effect is good. The filter material is clean and timely, which can ensure high-quality and stable water output, without periodic water quality fluctuations.
7. Easy to rebuild and expand, small footprint, beautiful appearance
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
