Advanced Equipment Used for Urban Sewage Treatment Tank Active Carbon Filter
Application
Activated carbon filters are widely used in the filtration of food, medicine, electronics, chemical, industrial wastewater and other industries.
Structure and Working Principle
Activated carbon filter is a kind of more commonly used water treatment equipment. As the pretreatment of water treatment desalination system, it can absorb residual chlorine that cannot be removed in the pre-filter, which can effectively ensure the service life of the subsequent equipment, improve the quality of the effluent, and prevent pollution, especially Prevent the post-stage reverse osmosis membrane, ion exchange resin and other free residual oxygen poisoning pollution. At the same time, it also adsorbs pollutants such as small molecular organics leaked from the previous stage, and has a relatively obvious adsorption and removal effect on peculiar smell, colloids and pigments, heavy metal ions in the water, and it also has the effect of reducing COD.
parameters
| Model | External dimensions | Maximum treated water volume(t／h) | Operating weight (ton) |
| GHT-1000 | Φ 1000*3150 | 7~9 | 4.58 |
| GHT-1500 | Φ 1500*3350 | 17~20 | 9.32 |
| GHT-2000 | Φ 2000*3780 | 31~37 | 15.5 |
| GHT-2400 | Φ2400*3900 | 45~54 | 21.85 |
| GHT-2600 | Φ 2600*3950 | 53~63 | 26.45 |
| GHT-2800 | φ 2800*4100 | 60~72 | 29.3 |
| GHT-3000 | Φ 3000*4200 | 70~80 | 33.55 |
| GHT-3200 | ф3200*4350 | 80~96 | 40.25 |
| GHT-3400 | ф 3400*4400 | 90~108 | 45.5 |
Main Features
1. Increase the degree of water purification and the service life of carbon.
2. Performance against peculiar smell, organic matter, colloid, iron and residual chlorine in the water body;
3. It also has a good effect on reducing the turbidity and chromaticity of the water body, purifying the water quality, and reducing the pollution of the subsequent systems (reverse osmosis, ultrafiltration, ion exchanger), etc.
4. High efficiency, low operating cost and low maintenance cost
5. Low one-time investment, small head loss, loose water quality requirements
6. The effluent quality is stable and the filtering effect is good. The filter material is clean and timely, which can ensure high-quality and stable water output, without periodic water quality fluctuations.
7. Easy to rebuild and expand, small footprint, beautiful appearance
Packing and Delivery
1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.
