Wastewater Treatment Tank Activated carbon filters
Application
Activated carbon filters are widely used in the filtration of food, medicine, electronics, chemical, industrial wastewater and other industries.
Structure and Working Principle
A tank filter device, the outer shell is generally stainless steel or glass fiber reinforced plastic, and the inside is filled with activated carbon to filter free substances, microorganisms, and some heavy metal ions in the water, and can effectively reduce the chromaticity of the water.
parameters
| Model | External dimensions | Maximum treated water volume(t／h) | Operating weight (ton) |
| GHT-1000 | Φ 1000*3150 | 7~9 | 4.58 |
| GHT-1500 | Φ 1500*3350 | 17~20 | 9.32 |
| GHT-2000 | Φ 2000*3780 | 31~37 | 15.5 |
| GHT-2400 | Φ2400*3900 | 45~54 | 21.85 |
| GHT-2600 | Φ 2600*3950 | 53~63 | 26.45 |
| GHT-2800 | φ 2800*4100 | 60~72 | 29.3 |
| GHT-3000 | Φ 3000*4200 | 70~80 | 33.55 |
| GHT-3200 | ф3200*4350 | 80~96 | 40.25 |
| GHT-3400 | ф 3400*4400 | 90~108 | 45.5 |
Main Features
1. Increase the degree of water purification and the service life of carbon.
2. Performance against peculiar smell, organic matter, colloid, iron and residual chlorine in the water body;
3. It also has a good effect on reducing the turbidity and chromaticity of the water body, purifying the water quality, and reducing the pollution of the subsequent systems (reverse osmosis, ultrafiltration, ion exchanger), etc.
4. High efficiency, low operating cost and low maintenance cost
5. Low one-time investment, small head loss, loose water quality requirements
6. The effluent quality is stable and the filtering effect is good. The filter material is clean and timely, which can ensure high-quality and stable water output, without periodic water quality fluctuations.
7. Easy to rebuild and expand, small footprint, beautiful appearance
